Blackmagic Design ATEM Mini Pro ISO Instruction Manual

Welcome to the Blackmagic Design ATEM Mini Pro ISO Instruction Manual. This guide provides step-by-step instructions on how to set up, operate, and optimize your ATEM Mini Pro ISO live production switcher — a powerful tool for multi-camera streaming and recording with professional quality.

Introduction

The ATEM Mini Pro ISO is a compact, versatile live production switcher designed for streaming, recording, and live switching of up to four HDMI inputs. The “ISO” version records each input separately as clean feeds, along with the program output and an edited project file, making post-production editing seamless. Blackmagic Design ATEM Mini Pro ISO

Package Contents

• ATEM Mini Pro ISO switcher

• USB-C power supply and cable

• USB-C to USB-A cable for computer connection

• Instruction manual

• Warranty card

System Requirements

• Operating System: Windows 10 64-bit or later / macOS 10.15 Catalina or later

• USB Port: USB 3.0 or higher for webcam output

• Internet connection for streaming

• Compatible HDMI cameras or video sources

Hardware Overview

Front Panel

• 4 HDMI Inputs: Connect cameras or other HDMI sources.

• Preview Buttons: Select preview inputs.

• Program Buttons: Select program (live output) inputs.

• Transition Buttons: Cut, auto (transition), and fade to black.

• Audio Mixer: 2 stereo inputs with volume knobs and mute buttons.

• Streaming Indicator: Shows streaming status.

• Record Button: Start/stop recording.

• Control Buttons: Include macro, power, and settings.

Rear Panel

• USB-C Output: Webcam output to computer.

• HDMI Program Output: Connect to external monitors or projectors.

• Ethernet Port: For streaming and control.

• Power Input: Connect power supply.

• Audio Input: 3.5mm stereo audio input jack.

Setup Instructions

Connecting Video Sources

1. Connect up to four HDMI cameras or devices to the HDMI inputs.

2. Connect an external monitor to the HDMI Program Output for viewing the live feed.

3. Connect stereo audio input if needed using the 3.5mm jack.

4. Connect the ATEM Mini Pro ISO to your computer using the USB-C cable.

Powering On

• Plug in the power supply and switch on the unit.

• The front panel LEDs will light up indicating power and status.

Network Setup for Streaming

• Connect the Ethernet cable to your router.

• The ATEM Mini Pro ISO will automatically obtain an IP address.

• Use the ATEM Software Control or the built-in web interface to configure streaming platforms (YouTube, Facebook, Twitch, custom RTMP).

Basic Operation

Switching Cameras

• Press the Preview button for the camera you want to cue.

• Press Cut or Auto to transition that input to the live program output.

• Use Fade to Black to cut to a black screen.

Audio Mixing

• Use the two audio input knobs to control volume.

• Mute buttons allow quick muting of audio channels.

• Embedded HDMI audio from camera inputs can also be mixed.

Streaming and Recording

• Press the Stream button to start or stop streaming.

• Press the Record button to begin or end ISO recording.

• The ATEM Mini Pro ISO records each input individually and the program output, plus an automatically generated DaVinci Resolve project file for editing.

Using ATEM Software Control

Download the free ATEM Software Control application from Blackmagic Design’s website for advanced control:

• Control transitions, effects, and keyers.

• Adjust audio mixing with more precision.

• Manage media pool for graphics and titles.

• Access macro controls for automating complex workflows.

ISO Recording Benefits

The ATEM Mini Pro ISO records:

• All 4 HDMI inputs as separate ISO files.

• The live program output.

• An automatically generated DaVinci Resolve project file with your live edit cuts and transitions, enabling easy post-production editing.

This allows you to:

• Fix mistakes after the fact by editing individual camera angles.

• Create alternate versions of your production.

• Sync audio and video easily in post.

Streaming Setup

1. Select your preferred streaming platform in the ATEM Software Control or via the web interface.

2. Enter your stream key or login credentials.

3. Confirm network settings.

4. Press the Stream button on the hardware to start streaming.

Media Management

• Load custom still images or graphics into the media pool via ATEM Software Control.

• Use upstream keyers to overlay logos, lower thirds, or other graphics.

• Manage transitions and fades for professional-quality live production.

Advanced Features

Picture-in-Picture (PiP)

• Use the DVE (Digital Video Effects) feature to create picture-in-picture overlays.

• Customize position, size, and border.

Macros

• Record sequences of actions as macros.

• Replay macros live to automate multi-step tasks.

MultiView Output

• Connect a MultiView monitor to see all cameras, program, preview, audio levels, and status on one screen.

Troubleshooting

Maintenance and Care

• Keep the unit clean and dust-free.

• Use a soft cloth to wipe the exterior.

• Ensure proper ventilation during use.

• Regularly update firmware via Blackmagic Design’s update tool.

Conclusion

The Blackmagic Design ATEM Mini Pro ISO is a versatile and powerful tool for live streaming and multi-camera production. By mastering its setup and operation, you can produce professional-quality streams with easy post-production capabilities.

For detailed tutorials, firmware updates, and support, visit Blackmagic Design’s official website.
